Structural characteristics of the partition assembler machine

As a specialized equipment for cardboard processing, the structural characteristics of the Full automatic partition assembler machine are as follows:

1、 Core mechanical structure

Rack design: Using high-strength metal frames (such as steel or aluminum alloy), high rigidity support is achieved through optimized mechanical distribution, which can withstand vibration and impact during continuous operation. Some models are equipped with adjustable anchor bolts to meet different ground flatness requirements.

Transmission system: The mainstream configuration is servo motor drive+precision ball screw, with a positioning accuracy of ± 0.1mm, combined with synchronous pulleys to achieve multi axis linkage. Some economical models use worm gear reduction mechanisms, which have lower costs but higher maintenance frequencies.

2、 Functional module characteristics of the cardboard partition assembler machine

Insertion mechanism: using pneumatic or electric push rod to control the insertion blade, with an adjustable stroke range of 50-300mm, supporting precise insertion of corrugated cardboard thickness of 0.5-5mm. High end models are equipped with a visual positioning system to achieve a ± 0.5mm accuracy in socket alignment.

Feeding system: The dual station automatic feeding platform is combined with a vacuum adsorption device, and the feeding speed can reach 30-60 times/minute, supporting continuous operation without stopping.

3、 Expand configuration

Human machine interface: 7-inch or larger touch screen integrated with PLC control system, supporting parameter preset and fault self diagnosis.

Safety protection: three insert partition assembly machine is equipped with infrared grating emergency stop device as standard, in compliance with CE safety standards. Some models can be equipped with dust collection modules to improve the working environment.
