The core of high-speed automatic printing die cutting slotting machine adjustment is to accurately adjust the three major links of paper feeding, printing, and forming, ensuring that the cardboard box size and printing quality meet the standards.
Adjustment steps for high-speed cardboard printing machine:
1、 Device initialization and self-test
After startup, the system automatically detects the status of servo drives, sensors, and other components to ensure their normal operation.
2、 Core process of size adjustment
Horizontal positioning adjustment
According to the width parameters of the cardboard box, the motor drives the screw to adjust the width of the side guard roller channel, and some Automatic cardboard printing slotting die cutting machine supports visual detection of micrometer level positioning.
Vertical feed adjustment
By changing the relative speed between the printing roller and the embossing roller, precise control of longitudinal dimensions can be achieved.
Printing pressure adjustment
Enter the thickness of the cardboard, and the system automatically calculates and adjusts the pressure of each color unit to avoid dirty printing or unclear graphics and text.
3、automatic carton printing slotting die cutting machine Technical principles and hardware support
Servo drive system: Real time correction of printing length errors, dynamic interpolation correction technology controls size deviations at the millimeter level.
Mechanical structure: Electric push rod or servo motor drives the height adjustment mechanism, and the side gear limit mechanism adapts to different thicknesses of cardboard boxes.
Sensor detection: Real time monitoring of carton position and conveying speed using photoelectric sensors, encoders, etc.
4、 Debugging and Testing
After low-speed trial operation, take cardboard for trial production, check whether the size, slotting, and pressure line meet the standards, and make minor adjustments if necessary.
