Product Description

Full automatic corrugated box flexo printer slotter die cutter machine

Lead edge flexo printer die-cutter slotter machine function:

The overall machine is designed and manufactured with high precision, intelligence, and safety in mind.

2. All transmission rollers are made of high-quality thick walled seamless steel, with heat treatment quenching and tempering, deep hole boring, surface grinding and hard chrome plating, and shaft head hot installation.

3. Spray painting process: The components undergo rust removal phosphating spray painting baking paint, which can prevent rust and harden the paint surface of the outer box, achieving beauty

Observe the role of corrosion resistance.

4. Gear material 45 # is used for grinding, quenching and tempering, increasing hardness, and grinding, with a Rockwell hardness of 52-56 degrees.

5. Apply a tightening sleeve without a key connection ring to reduce center wear, enlarge virtual positions, and maintain long-term printing accuracy.

6. Each unit automatically resets to zero.

7. Touch screen control, capable of storing orders up to 999 items.

8. Each unit is equipped with an emergency stop switch, which can stop the movement of each unit internally to ensure the safety of internal operators.

9. Each unit of the whole machine is automatically or independently separated, making operation more convenient. When walking, it continuously rings a warning bell to ensure the safety of operators.

10. The clearance between the rubber shaft and the pressure line is adjusted by manual self-locking, with a self-locking structure.

11. The wall panel is made of carbon steel with a thickness of 50mm. It undergoes 24-hour medium frequency quenching and tempering to increase its density and hardness. It is paired with a large machining center for processing.

Full automatic corrugated box flexo printer slotter die cutter machine

Automatic flexo printer die cutter slotter machine Characteristic:

1. The whole machine according to the high reliability requirements, functional design and manufacturing, design of machine operation of human nature, can be set, modification, replacement, execute, memory function in a short period of time, and display with accurate data.

2. All the drive rollers are made of high-quality steel, hard chrome plated surface grinding.

3. The drive gears adopt high quality alloy steel, after heat treatment, grinding into.

4. The main drive shaft using the free connection, reduce the gap of the connection, ensure the printing overprint precision.

5. Oil automatic balance device, keep the unit oil surface balance.

6. The Corrugated carton flexo printer die cutter slotter machine adopts PLC control, with zero, memory functions (can be used PLC combined with touch screen control)

7. Front type feed method.

8. Anilox roller: can use metal net roll or ceramic anilox roll, net roller line number according to the requirements of users can select.

Full automatic corrugated box flexo printer slotter die cutter machine

After-sale Service:

1.Machine quality control

supply install and test the machine in working condition before shipment.Welcome to the company to test the machine before shipment.

2.installing and Commission:

install the machine at customer factory is available

we will send technician there. All our expenses including double way air ticket to the nearest airport, local transportion to your factory, Lodging&Boarding expenses shall be payable by you. .

3.Warranty period:

One year for fully machine guarantee. And in this year if the machine broken caused by mechanical problem, all of the spare part is free.

Service time :

4.24 hours technical support.

FAQ:

1. Are you a factory or trading company?

We are both a factory and a trading company in this field .

2.What's your payment term?

We usually accept the T/T payment, we need 30% of total amount as deposit,

pay the 70% balance before delivery, but we can also accept the L/C.

3.Which country have you sold before?

North America,South America,Egypt,South Africa,Southeast Asia and India.

4.Where is your factory located ? How can I visit there?

Our factory located in Dongguang County, Hebei Province, China., near to the

capital city Beijing and port Tianjin. You can fly to Beijing airport directly and we

will pick you up there.

5. How does your factory do regarding quality control?

Quality is priority. We always regard great importance to quality controlling from

the very small thing(even a small screw we will choose the best quality) from the beginning.

6.What about the after-sales service?

After you buy the machines,we can go to your country to install and repair .

Our Service:

Pre-Sales Service

1. Inquiry and consulting support.

2.View our Factory.

After-Sales Service

1. Installation, training how to use the machine and technical support.

2. Engineers available to service machinery overseas.
